D-6209
Waterproof Silicone Keyboard for Portable Computers
Designed for rugged computers, our silicone keyboard provides reliable performance in harsh environments. With a sealed waterproof design, excellent durability, and customizable options, it is ideal for military, industrial, medical, transportation, and outdoor applications where dependable operation is essential.
- Fully Sealed Protection for Harsh Environments
- Built for Long-Term Reliability
- Comfortable and Accurate Typing
- Easy to Clean and Disinfect
- Backlit key characters ensure usability even in dim light
D-6209
Waterproof Silicone Keyboard for Portable Computers
D-6209
Waterproof Silicone Keyboard for Portable Computers
Materiais de alta qualidade
Industrial-grade silicone & 6061 Aluminum
Military-grade Standards
Electroless Nickel Immersion Gold PCB
Nível de proteção
IP66 protection level
-- A melhor solução para si
Fully Sealed Surface Design
Industrial-grade silicone, molded as a single, seamless unit; the front face achieves an IP66 protection rating and is easy to clean, allowing for washing or wiping with disinfectant.
—— Application Scenarios
The Top Choice for Specialized Portable Computers
Our ruggedized silicone keyboards are widely used in specialized portable computers and vehicle-mounted systems. They not only function reliably under conditions of intense vibration and wet, rainy weather but also withstand extreme temperatures(-40℃~+70℃), making them the ideal choice for harsh environments.
Tamanho do produto
Especificações
| Propriedades físicas | |
| Tamanho do painel | 282.5×178.5mm |
| Interface de comunicação | USB |
| Número de chaves | 87+2 |
| Viagens importantes | ≈1,5 mm |
| Pressão-chave | ≈1,5N±0,2N |
| Chave individual Vida | ≈200W vezes |
| Material essencial | Silicone |
| Material do painel | Silicone |
| Material do chassis | Alumínio 6061 |
| Artesanato PCB | Imersão em ouro |
| Iluminação de fundo das teclas | Yes |
| Tamanho da chave | 12.84×12.84mm |
| Peso líquido | ≈1Kg |
| Modo de disparo | Grão de carbono |
| Propriedades eléctricas | |
| Interface de comunicação | USB 2.0 |
| Compatibilidade do sistema | Win, Linux, etc. |
| Tensão de funcionamento | 5V±0.25 |
| Corrente de trabalho |
≤50mA(Turn off backlit) ≤200mA(Turn on backlit) |
| Potência máxima | ≈0.15W |
| Itens de teste | |
| Nível de proteção | IP66 |
| Temperatura de funcionamento | -40°C~70°C |
| Temperatura de armazenamento | -45°C~85°C |
| Tempo médio até à falha | >20000H |
| Tempo médio de reparação | <30M |
